SD-0150
General Purpose ABS, SD – 0150 grade, is a rigid thermoplastic with good processing characteristics.
Description
SD-0150
ACRYLONITRILE BUTADIENE STYRENE(ABS)
Product Description
General Purpose ABS, SD – 0150 grade, is a rigid thermoplastic with good processing characteristics. It is a high flow injection molding grade with considerable impact strength and medium heat deflection.
Applications:
This grade is intended for a wide range of applications including:
- auto parts,
- home appliances,
- electrical parts/fittings,
- Telecommunication and electronic devices.
| PROPERTY | TEST METHOD | TEST CONDITION | UNIT | TYPICAL VALUE |
| MFI | ASTM D 1238 | (200ºc/5kg) | Gr/10 min | 1.7 |
| Izod Impact Strength (notched) | ISO 180 | 1/8 inch | Kj / m2 | 25 |
| Tensile Strength @ Yield | ASTM D 638 | 5mm/min | Kgf /cm2 | 440 |
| Elongation @ Break | ASTM D 638 | 5mm/min | % | 40 |
| Flexural Strength @ Yield | ASTM D 790 | 2.8mm/min | Kgf /cm2 | 640 |
| Flexural Modulus | ASTM D 790 | 2.8mm/min | Kgf /cm2 | 20500 |
| Vicat Softening Temperature (unannealed) | ASTM D 1525 | 5kg | ºC | 99 |
| Rockwell Hardness | ASTM D 785 | – | R-Scale | 104 |
| Flammability | UL 94 | 1.5mm Specimen | Recognized | HB |
Typical Data :
Density of this grade is approximately1.04 gr/cm3.
Shrinkage of all ABS grades in mold is approximately 0.3 % ~ 0.6 % (ASTM D 955).
All tests are carried out at 23 ºC unless otherwise stated.
The above data are typical laboratory average. They are intended to serve as guide only.
Processing Condition :
SD – 0150 ABS granules absorbs moisture from atmosphere, with a rate depending on temperature and humidity. It is recommended that the material be dried in a dehumidifying dryer at 80 °C to 85 °C for 2-4 hours, prior to use.
Processing temperatures are recommended to be set at 190°C- 230 °C for cylinder, and 40 °C to 80 °C for mold. SD-0150 ABS can be processed under different conditions based on machinery available and articles molded.
Additional information
| MFI (dg/min): |
1.7 ( 200ºC/5Kg ) |
|---|---|
| Application(s): |
•auto parts •home appliances •electrical parts/fittings •Telecommunication and electronic devices. |
